Evt 4000e User Manual
1.EVT-4000E Electric Scooter Operation Manual. Contents: Page 1. Introduction Operation Parts Position. 7.Side View. 7.Back View 8 4. Basic Functions.
Instrument Panel. Main Switch Lock Method Release the Lock.
Left Handle Bar Control and Switch. 11. Right Handle Bar Control and Switch 12. Seat Lock Helmet Clip Inspections (Prior to driving) Trouble Shooting and Repair (1) Trouble Shooting and Repair (2) Periodic Maintenance Table Specifications (1)EVT-4000E.Lead-Acid Battery Specifications (2)EVT-4000E.Lithium Polymer Battery2 1. Introduction: Dearest User: 1.
Thank you for choosing the EVT Electric Scooter. We hope you have a pleasant time riding it. This manual will help you understand the operation, basic inspection and maintenance of your scooter.
It will also explain how to get the best performance and how to make your riding safer. The contents of this manual may be slightly different from your scooter. EVT Technology Co., Ltd. Reserves the right of final explanation and modification of contents and specifications of this manual without notice. Operation: Launch 1. Hold the left handle bar and brake lever with your left hand, hold the lift bar with your right hand.
Push the scooter forward; the main stand will jump up. The side stand will jump while the scooter is moving forward. Mount the scooter from the left side and sit well, keep your left foot on the ground to balance the scooter. Turn the key to ON position to turn the power on and wait till the flashing LEDs on the dashboard and starting beep sound stop in about 3 seconds, and then gently twist the throttle to pull away the scooter. Do not twist the throttle while the LEDs are still flashing, if so, the warning beep shall sound.
Please re-turn the key to ON position and wait till the flashing LEDs and starting beep sound stop. Do not leave the key in the ON position when the rider is not seated. Be sure to turn the key to OFF when the rider is not seated. 23 On Driving 1. Release the brake lever; gently twist the throttle to pull away the scooter. While braking, apply front and rear brakes together to prevent the scooter becoming unbalanced.
Keep the light on while driving at night or in dark condition. Always switch to low bean when on-coming traffic is approaching. The driving range will be reduced in different driving conditions, i.e.: quick acceleration, excessive braking, lights on driving, head-wind, carrying heavy loading, slope climbing, low tire pressure, low temperature and insufficient recharge. If power shut off whilst braking, release the brakes and power supply resumes automatically in 0.5 seconds. Over heat and over current will reduce the power by half or shut it off completely. Please turn the key to OFF position, wait for few minutes till the system to cool down then turn the key to ON position to start driving again.
Quick acceleration from standstill, high degree slope climbing or heavy loading driving will make the battery voltage drop quickly. The controller will detect the battery low voltage and cut the power to protect the battery. Please turn the key to OFF position, wait for few seconds then turn the key to ON position to start driving again. When around 10% of battery energy left (yellow LED on), quick acceleration may cut off the power. Strongly recommend to fully recharge when around 10% of battery energy left (yellow LED on). When the scooter is at a standstill, put your left foot on the ground and turn the key to OFF position.
Get off the scooter from left side, hold the left handle bar and brake lever with your left hand. Hold the lift bar by your right hand, step on the paddle on the main stand with your right foot, pull the scooter backwards. Turn the handle bar to the leftmost position and shake it a little bit, turn the key to LOCK position and then take the key out.
34 Scooter Charging 1. Make sure the scooter is at OFF position and with the key out. The Charging time depends on the battery energy left. The standard charging time is 5 to 6 hours as power almost drained and will provide on average up to 90% battery energy. To fully charge up to 100% battery energy level shall take another 2 to 3 hours.
Charger working with Lead-Acid Battery (A) Off-Board Charger a. Charger shall be put in the dry and ventilated area. Rain or moisture will damage the charger. Insert the DC connector into the scooter firmly, and the AC connector into the standard outlet. Check the 4 LEDs on the charger to realize the charging condition. Unplug the AC and DC connector after charging is completed.
4Leds on Charger Orange LED on Green LED on No LED on Status Charging in progress Fully Charged Charger failure 4. 5 (B) On-Board Charger a.
Do not Charge the scooter outside in the rain. Rain or moisture will damage the charger. Insert the AC connector into the standard outlet.
Check the 4 LEDs on the dashboard to realize the charging condition. Unplug the AC connector after charging is completed. 4Leds on Dashboard Status LEDs constantly flashing in 2 seconds. Charging in progress LEDs on Fully Charged No LED on Charger failure 56 4. Charger working with Lithium Battery a. Charger shall be put in the dry and ventilated area. Rain or moisture will damage the charger.
Insert the DC connector into the scooter firmly, and the AC connector into the standard outlet. Check the LEDs on the charger to realize the charging condition. Unplug the AC and DC connector after charging is completed.
Led on Charger Red LED on Green LED on No LED on Status Charging in progress Fully Charged Charger failure 5. Different battery pack should work with different charger to assure the best recharging performance. Recharging battery with wrong charger may cause serious damage to charger or to battery. The battery life cycle will be reduced or damaged if insufficient charge status is retained for a long period of time. Please keep charging the batteries in the sufficient status.
If the scooter is not going to be used for a long period, keep recharging the batteries at least once every two weeks. 9 Instrument Panel 4. Basic Functions 1. Speedometer 2.Odometer 3.Overheat Indicator (O.H) 4. High Beam Indicator 5.Direction Lamp Indicator 6. Battery Energy Indicator (E-F) & Charging Status Item Name Functions 1 Speedometer Driving speed 2 Odometer Mileage Recorder (km) 3 Overheat Indicator (O.H) On - when temperature reaches upper limit 4 High Beam Indicator On - when switch to high beam 5 Direction Lamp Indicator On - when direction indicator selected 6 Battery Energy Indicator (E-F) 1.
Evt 4000e User Manual Instructions
Full Energy: First green light on 2. 50% Energy Left: Second green light on 3. 10% Energy Left: Yellow light on and warning beep sound (charging recommend) 4. Reached Lower Safety Limit: Red Light on (N.B). No energy (charging immediately) 9.
10 Main Switch LOCK Handlebar is locked. The key can be pulled out. OFF Power is off.
The key can be pulled out. ON Power is on. The key can not be pulled out. To prevent theft, remember to turn the key to the correct position and take the key out when parked. Lock Method Turn the turning bar fully to left, press the key and then release, turn the key to the lock and shake a little bit. The key can be turned to the correct position and pulled out. Release the Lock Insert the key, shake the turning bar a little bit.
The key can be turned to the correct position and the lock is then released. 11 Left Handle Bar Control and Switch 1. Hi-Lo Switch for Headlamp: When front lamp switch is on (1) -Front lamp is on high beam (2) -Front lamp is on low beam 2.
Switch of direction lamp: (1) -Front right, rear right direction lamp flashing and intermittent beep sound. (2) -Front left, rear left direction lamp flashing and intermittent beep sound. Note: After turning, push the bottom on the switch to switch off. Horn Button: Horn sound while pressing down. Rear Brake Lever: Hold tight to break the rear wheel and cut off the power.
If the power cut off while braking, release the lever and the power will resume automatically. 12 Right Handle Bar Control and Switch 1. Acceleration Throttle: Will vary the speed and power when twist by different amount. Headlamp Switch: -Front Lamp, display panel lamp and tail lamp on.Front Lamp, display panel lamp and tail lamp off. Kill Switch: (US model) -Kill Switch ON - Scooter will sound an alarm if started in this position.Kill Switch OFF - Normal operations position for this switch. Switch for Power/Economic (P/E) Mode. Selected by user when driving on different road conditions.
Front Brake Lever: Hold tight to break the front wheel and cut off the power, If the power cut off while braking, release the lever and the power will resume automatically. Notes:.Twist the acceleration throttle slowly when pulling away. When the scooter starts to move the throttle can be turned more to reach the required speed.When the scooter is parked and no one is seated or the rear wheel is on the ground, do not twist the throttle. Otherwise, it is possible for the rear wheel to be driven.Release the throttle before applying the brake levers and release the levers before reapplying the throttle to drive. 13.There is no sound when the main switch is at ON position; the motor is also on and in standby position. For safety reason, the yellow LED shall be flashing and with beep warning 10 seconds while the scooter is at ON position for 5 minutes without any moving. Return the key to ON position to restart the scooter.
Always take the key out to prevent serious damage or injury happen if there is no rider on the scooter. Insert the key to the seat lock and turn to the right, the lock will release. Lift up the seat. Close the seat with a little pressure and it will lock automatically, try to lift the seat to make sure it is well locked. Helmet Clip 1. Open the seat.
Place the helmet clip ring on the clip. Close the seat to lock automatically. Repeat this process to remove the helmet. Inspections (Prior to driving) Maintaining regular inspection will improve driving safety.
Tire: Pressure, Gaps, Any Cut, Damaged. Brakes: Gaps of left and right brakes are normal (1-2cm is normal). Sufficient brake fluid. Lamps: Direction Lamps, Brake Lamps, Front Lamp. Rear View Mirrors: The angles are correct. Turning Bar: Operating smoothly.
Energy Indicator: Battery energy is sufficient for reaching to the destination. Trouble Shooting and Repair (1) Conditions Inspect Repair Instrument Panel LED is working, but there is no move while twisting throttle. Instrument Panel LED is not working or no starting beep sound while you turn the switch to the ON position.
The first red LED flashing (1) 1.The power will cut off while braking 2. Brake switch breakdown. Motor breakdown. Controller breakdown. 1.Has the fuse blown? 2.Serious insufficient energy left.
3.Key switch breakdown. 4.Controller breakdown.
5.Display panel breakdown. 1.Serious insufficient energy left 2.The battery is aged or useless 1.Release the brake and then gently twisting throttle. 24.See your agent 1. Remove the fuse and replace or see your agent 2. Recharge battery 35.See your agent 1.Recharge battery immediately 2.Replace the battery The second yellow LED flashing (2) Insufficient energy left Recharge battery The third green LED flashing (3) DC converter See your agent 1617 7.
Trouble Shooting and Repair (2) Conditions Inspect Repair 4 LEDs flashing sequentially 1.Throttle stuck 2.Twisting throttle to pull away after the panel indicator stops flashing or the starting beep sound stops The OH indicator lit(5) 1.Controller over heat 2.Controller breakdown The OH indicator flashing 1.Motor over heat. 2.Motor breakdown.
1.See your agent 2.Switch the power to OFF position, and wait for few seconds to restart 1.Switch the power to OFF position, and wait for several minutes than restart. 2.See your agent 1.Switch the power to OFF position, and wait for several minutes than restart. 2.See your agent. The first red LED lit (For scooter working with lithium battery only) Battery pack breakdown.
See you agent. Notes: (US model) Switch on Kill Switch should cut off the power, switch off Kill Switch and return the key to ON position to start moving scooter. Scooter must be started with Kill Switch in the off position to function. Periodic Maintenance Table A: Inspection C: Clean T: Tighten Item Mileage(km) More A. Controller A A B. Battery A A A A C. Charger A A A A D.
Safety 1.Pressure A A A A A A A A A A A A 2.Tire A A A 3.Brakes A A A A A A A A A A A A A REPEATITEM Brake Linings A A A E. Lamp, Horn A A A A A A A A A A A A A F. Screws T T T T T T T T T T T T T G. Turning & Transmission A A C A C 1819 BBBDDDIIIIMMMMEEEENNNNTTTTTTTTEEEERRRRYAAAYYYSSSSIIIIOOOONNNNPPPEEEERRRRFFFFOOOORRRRMMMMAAAANNNNCCCCEEEEMMMOOOOTTTTOOOORRRR9.
